SV04 Direct Drive Independent Dual Metal Titan Extruder 3D Printer 300 x 300 x 400 mm

US $249.00US $639.00
  • SV04 Direct Drive Independent Dual Metal Titan Extruder 3D Printer 300 x 300 x 400 mm
  • SV04 Direct Drive Independent Dual Metal Titan Extruder 3D Printer 300 x 300 x 400 mm
  • SV04 Direct Drive Independent Dual Metal Titan Extruder 3D Printer 300 x 300 x 400 mm
  • SV04 Direct Drive Independent Dual Metal Titan Extruder 3D Printer 300 x 300 x 400 mm
  • SV04 Direct Drive Independent Dual Metal Titan Extruder 3D Printer 300 x 300 x 400 mm
  • SV04 Direct Drive Independent Dual Metal Titan Extruder 3D Printer 300 x 300 x 400 mm

SV04 Direct Drive Independent Dual Metal Titan Extruder 3D Printer 300 x 300 x 400 mm

US $249.00US $639.00
US $249.00US $639.00
  • 💰 Earn Points with Login:
    Earn points and get membership exclusive perks with your account login.
    Sign up now and get $5 off for your first purchaseClick to learn more.

    🎁  Get Rewards with Your Points
    Turn points into discount code.
    Get early access to sales and new products before the rush.

  •  ● 1-year Warranty & 30-day Guarantee

    Every printer comes with the warranty of 12 months, and we offer 30-day exchange/refund/return guarantee if the printer has unfixable issue.

    ● Technical Support

    Sovol Support Team is available via email and live chat.
    Join Sovol User Group to get tips from employees and community.

Order Fulfillment Notice:

1. Available quantity: 5. First come first serve, and limited to one per person. We will only fulfill the order from the people who received our invitation email.

2. The SV04 printers will be shipped from China and it would take 7-10 days for delivery.

3. Please understand that we don't accept the return for this item. We would declare the real price for the order and you may need to pay a customs fee if there is any.

SV04
SV02
Printing Technology Independent Dual Extruder (Direct Drive) Dual Extruder (2-in-1-out)
Build Volumn 300 x 300 x 400 mm 280 x 240 x 300mm
Auto Leveling BL Touch Preinstalled Support BL Touch
Mainboard 32-bit TMC2209 Silent Board 8-bit TMC2208 Silent Board
Runout Sensor Yes No
Belt Tensioner Yes No

Technical Specifications

● Extrusion Tech: Independent Dual Metal Titan Extruder (IDEX)
● Build Size: 300 x 300 x 400mm
● Printer Dimensions: 587.4mm (L) x 674.9mm (W) x840mm (H)
● Package Dimensions: 735mm (L) x 735mm (W) x 305mm (H)
● Net Weight: 13.8kg
● Layer Resolution: 0.1mm
● Positioning Accuracy: X/Y 0.012mm Z 0.001mm
● Supported Print Materials: PLA, TPU, HIPS, ABS, PETG, WOOD
● Print Speed: 20~120mm/s(suggested 60mm/s)
● Stock Nozzle Diameter: 0.4 mm
● Operational Extruder Temperature: Max 260ºC
● Input Formats: .STL, .OBJ, .DAE, .AMF
● Ambient Operating Temperature:8ºC - 40ºC
● Connectivity: SD Card or Data Cable
single printing mode

Independent Dual Extrusion allows you to do 4 printing modes: Single Material Printing, Dual Material Mode, Duplication Mode Printing and Mirror Mode Printing.

single printing mode

Independent Dual Extrusion allows you to do 4 printing modes: Single Material Printing, Dual Material Mode, Duplication Mode Printing and Mirror Mode Printing.

single printing mode

Independent Dual Extrusion allows you to do 4 printing modes: Single Material Printing, Dual Material Mode, Duplication Mode Printing and Mirror Mode Printing.

single printing mode

Independent Dual Extrusion allows you to do 4 printing modes: Single Material Printing, Dual Material Mode, Duplication Mode Printing and Mirror Mode Printing.

direct drive extruder

Dual Metal Titan Extruder leads to faster retraction with more accurate extrusion, allowing you to not only print with more flexible materials but also have better overall extrusion.

auto leveling bl touch

Auto-leveling SV04 will make adjustments to ensure the bed and nozzle are at an optimum distance throughout the printing, which improves bed adhesion and print quality.

tmc2209 silent board

32-bit TMC2209 board has a resolution upwards of 256 individually smaller, high-res steps and thus less noise is generated in the coils of the motor.

touchscreen

Comes with 4.3 inch LCD touch screen color display. Operating with an responsive and sensitive touch button, all the modes are clear and easy to use.

dual z axis

Flexible Magnetic Build Plate ensures your print can get a good grip to it, to help prevent warping and failed prints. allows you pop off the prints without any tool, just spring the plate and your print will pop off.

dual z axis

Dual Z-axis screws and stepper motors improve the accuracy and precision of nozzle's vertical movement with a specified Z-axis accuracy of 0.001mm.

meanwell power supply

Built-in 500W Meanwell power supply ensures stable and sufficient power, fast heatup for the hotbed and nozzle. It protects SV04 from unexpected power surges.

filament runout sensor

No worry for long print that will run out your filaments and cause any problems. No epic print failures anymore with SV04!

touchscreen

300 x 300 x 400mm build volume makes SV04 the best large format independent dual exdruder direct drive printer in the market.

adjustable belt tensioner

Adjustable belt tensioners make SV04 achieve proper belt tension to get high quality prints.


Resume printing function allows you turn off SV04 while printing, and resume your print from last layer anytime later.
