● 1-year Warranty & 30-day Guarantee
Every printer comes with the warranty of 12 months, and we offer 30-day exchange/refund/return guarantee if the printer has unfixable issue.
● Technical Support
Note: Don't worry about the price, it will be VERY NICE! (The price on our website is NOT the Final Price)
|Printing Technology||Independent Dual Extruder (Direct Drive)||Dual Extruder (2-in-1-out)|
|Build Volumn||300 x 300 x 400 mm||280 x 240 x 300mm|
|Auto Leveling||BL Touch Preinstalled||Support BL Touch|
|Mainboard||32-bit TMC2209 Silent Board||8-bit TMC2208 Silent Board|
- ● Extrusion Tech: Independent Dual Metal Titan Extruder (IDEX)
- ● Build Size: 300 x 300 x 400mm
- ● Printer Dimensions: 587.4mm (L) x 674.9mm (W) x840mm (H)
- ● Package Dimensions: 735mm (L) x 735mm (W) x 305mm (H)
- ● Net Weight: 13.8kg
- ● Layer Resolution: 0.1mm
- ● Positioning Accuracy: X/Y 0.012mm Z 0.001mm
- ● Supported Print Materials: PLA, TPU, HIPS, ABS, PETG, WOOD
- ● Print Speed: 20~120mm/s(suggested 60mm/s)
- ● Stock Nozzle Diameter: 0.4 mm
- ● Operational Extruder Temperature: Max 260ºC
- ● Input Formats: .STL, .OBJ, .DAE, .AMF
- ● Ambient Operating Temperature:8ºC - 40ºC
- ● Connectivity: SD Card or Data Cable
Independent Dual Extrusion allows you to do 4 printing modes: Single Material Printing, Dual Material Mode, Duplication Mode Printing and Mirror Mode Printing.
Dual Metal Titan Extruder leads to faster retraction with more accurate extrusion, allowing you to not only print with more flexible materials but also have better overall extrusion.
Auto-leveling SV04 will make adjustments to ensure the bed and nozzle are at an optimum distance throughout the printing, which improves bed adhesion and print quality.
32-bit TMC2209 board has a resolution upwards of 256 individually smaller, high-res steps and thus less noise is generated in the coils of the motor.
SV04 equips with dual metal titan extruders which are more capable to produce high quality prints across a vast range of material.
SV04 comes with new cable management system which hosts numerous wires, cables and other clutters organized, the new design keeps your work area much cleaner.
SV04 equips with SD card slot, and a SD card is included in the package. This is a small upgrade but it means a lot for lots of people who are fed up with the micro card and micro slot.
Comes with 4.3 inch LCD touch screen color display. Operating with an responsive and sensitive touch button, all the modes are clear and easy to use.
Flexible Magnetic Build Plate ensures your print can get a good grip to it, to help prevent warping and failed prints. allows you pop off the prints without any tool, just spring the plate and your print will pop off.
Dual Z-axis screws and stepper motors improve the accuracy and precision of nozzle's vertical movement with a specified Z-axis accuracy of 0.001mm.
Built-in 500W Meanwell power supply ensures stable and sufficient power, fast heatup for the hotbed and nozzle. It protects SV04 from unexpected power surges.
No worry for long print that will run out your filaments and cause any problems. No epic print failures anymore with SV04!
300 x 300 x 400mm build volume makes SV04 the best large format independent dual exdruder direct drive printer in the market.
Adjustable belt tensioners make SV04 achieve proper belt tension to get high quality prints.
Resume printing function allows you turn off SV04 while printing, and resume your print from last layer anytime later.
